A&D HVW-04C COMPARATOR RELAY OUT/BUZZER for HVW-C and HVW-C/CP

Roll over image to zoom in Click on image to zoom

A&D Weighing HVW-04C COMPARATOR RELAY OUT/BUZZER for HVW-C and HVW-C/CP

Name: A&D Weighing HVW-04C COMPARATOR RELAY OUT/BUZZER for HVW-C and HVW-C/CP
Brand: AND Weighing
SKU: HVW-04C
Price: 161.25 USD
Availability: InStock

Save $53.75

Authorized AND Weighing DistributorSKU: HVW-04C

Price:

$161.25 $215.00

Shipping calculated at checkout

Stock:

In stock

Quantity:

Pickup currently unavailable at 14637 Arminta Street

Share this product

COMPARATOR RELAY OUT/BUZZER for HVW-C and HVW-C/CP. Click here for the A&D HVW-14 ROLLER CONVEYOR A36099

brand	A&D Weighing
lead-time	4
list-price	215.00
manufacturer-part-number	HVW-04C

All Sales outside of the US and Canada are final (NO REFUNDS/RETURNS/EXCHANGE).
Qualified Returns/Refunds/Exchange SHOULD BE MADE WITHIN (14) DAYS FROM DELIVERY DATE.
Returns from sales within US and Canada will be subject to inspection to determine condition of the item/s.
Only items that are brand new condition with ALL the parts and accessories that came with the box including the original packaging materials will be accepted.
Any used or opened items such as, but not limited to, accessories, supplies, and consumables are NOT returnable or exchangeable. Shipping and handling are non-refundable as well.
Customer will assume responsibility and will pay for shipping item/s for return or exchange.
Qualified return item/s will be issued 100% store credit for exchange and/or future purchases of items with the SAME BRAND or made by the same manufacturer.
A 25% RE-STOCKING FEE WILL APPLY for refund or to purchase another item/s of a brand different from the original purchase.

Country

Province

Zip code

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

We offer Net 30 terms for qualified business customers, allowing you to receive your order now and pay within 30 days of the invoice date.

Frequently Asked Questions

What does the A&D HVW-04C Comparator Relay Output/Buzzer do?

The A&D HVW-04C adds comparator relay output, an audible buzzer, and contact input functionality to compatible A&D platform scales. It allows checkweighing results to trigger external equipment or audible alerts, making it useful for production, sorting, filling, packaging, and quality-control applications.

What comparator relay outputs are available on the A&D HVW-04C?

The HVW-04C provides five comparator relay outputs: HIHI, HI, OK, LO, and LOLO, plus a common terminal. These outputs can communicate different checkweighing results to compatible external equipment such as signal lights or control systems. When three-level comparator mode is selected, the interface uses the HIHI, OK, and LOLO outputs.

How does the buzzer function work on the HVW-04C?

The HVW-04C has a buzzer built into its circuit board that can sound according to the scale's comparator results. Users can configure which comparison conditions activate the audible alert. A&D specifies an approximate sound pressure level of 58 dB at 1 meter from the display unit, making the feature useful when operators need an audible indication in addition to the scale's LED comparator lights.

What are the electrical ratings of the HVW-04C relay outputs?

A&D specifies the HVW-04C solid-state relay outputs for a maximum of 50 V DC and 100 mA DC, with a maximum ON resistance of 8 Ω. These ratings should be followed when integrating the interface with external control equipment, indicators, or other compatible devices.

Can the HVW-04C be used with USB or RS-232C interfaces on the same scale?

Yes. A&D's HV/HW-C/CP platform supports separate optional interfaces. The HVW-04C handles comparator relay output, buzzer, and contact input, while the HVW-02CB provides USB communication and the HVW-03C provides RS-232C. A&D documentation shows the HVW-04C can be installed alongside optional data-communication interfaces in supported configurations.
