A&D FX-500i FX-i Series Precision Balance

Roll over image to zoom in Click on image to zoom

A&D Weighing FX-500i FX-i Series Precision Balance (Replaced by FX-523), 520 g x 0.001 g

Name: A&D Weighing FX-500i FX-i Series Precision Balance (Replaced by FX-523), 520 g x 0.001 g
Brand: AND Weighing
SKU: FX-500i
Price: 1242.50 USD
Availability: InStock

Save $532.50

Authorized AND Weighing DistributorSKU: FX-500i

Price:

$1,242.50 $1,775.00

Shipping calculated at checkout

Stock:

In stock

Same Day Shipping

Quantity:

Pickup available at 14637 Arminta Street

Usually ready in 1 hour

Share this product

520 g x 0.001 g with Breeze Break (3.4

brand	A&D Weighing
calibration	External calibration
capacity-g	520
counting-mode	FXi-02, FXi-08 and FXi-09 cannot be used at the same time. (see Accessories below)
custom-stock-status-message	Same Day Shipping
dimensions	7.6" x 10.3" x 3.3" / 193 mm x 262.5 mm x 84.5 mm
display	Vacuum Fluorescent Display (VFD)
display-update	5 times/second, 10 times/second or 20 times/second
Legal-for-Trade	No
linearity	±0.002 g
list-price	1775.00
Manual	FX-500i_Manual.pdf
manufacturer-part-number	FX-500i
model	FX-i Series
net-weight	5.5 lb / 2.5 kg
operating-temperature	5ºC - 40ºC / 41ºF - 104ºF, 85% RH or less (No condensation)
pan-dimension	5.1" / 130 mm diameter
pan-size	5.12" / 130 mm dia.
percent-mode	0.001 g
Power	AC adapter, optional battery
promotion
readability-g	0.001
resolution	520 g x 0.001 g 18.34 oz x 0.00005 oz 1.14 lb x 0.000005 lb 0 lb, 18.34 oz x 0.01 oz 16.71 ozt x 0.00005 ozt 2,600 ct x 0.005 ct 335.1 dwt x 0.001 dwt 8,024 GN x 0.02 GN
send-browsed-product-autore	1
sensitivity-drift-ppm-c	±2 ppm / ºC
stabilization-time	Programmable, Can be as fast as 1 second
warranty-covering-parts-and	5 Year Warranty
Weighing-Units	g, oz, lb, lb-oz, ozt, ct, mom, dwt, GN, tl, tol, mes, pcs, %, MLT

All Sales outside of the US and Canada are final (NO REFUNDS/RETURNS/EXCHANGE).
Qualified Returns/Refunds/Exchange SHOULD BE MADE WITHIN (14) DAYS FROM DELIVERY DATE.
Returns from sales within US and Canada will be subject to inspection to determine condition of the item/s.
Only items that are brand new condition with ALL the parts and accessories that came with the box including the original packaging materials will be accepted.
Any used or opened items such as, but not limited to, accessories, supplies, and consumables are NOT returnable or exchangeable. Shipping and handling are non-refundable as well.
Customer will assume responsibility and will pay for shipping item/s for return or exchange.
Qualified return item/s will be issued 100% store credit for exchange and/or future purchases of items with the SAME BRAND or made by the same manufacturer.
A 25% RE-STOCKING FEE WILL APPLY for refund or to purchase another item/s of a brand different from the original purchase.

Country

Province

Zip code

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

We offer Net 30 terms for qualified business customers, allowing you to receive your order now and pay within 30 days of the invoice date.

Frequently Asked Questions

What are the capacity and readability of the A&D FX-500i Precision Balance?

The A&D FX-500i offers a maximum capacity of 520 g with 0.001 g (1 mg) readability. It also provides 0.001 g repeatability and ±0.002 g linearity, making it suitable for laboratory testing, formulation, sample preparation, quality control, and production applications that require milligram-level measurements.

How fast does the A&D FX-500i stabilize?

The FX-500i can stabilize in approximately 1 second when set to FAST under suitable environmental conditions. Its fast response helps users complete repetitive weighing tasks efficiently while maintaining 0.001 g readability.

Does the A&D FX-500i have internal or external calibration?

The FX-500i uses external calibration, meaning an appropriate external calibration weight is required for calibration. Buyers who prefer built-in internal calibration can consider the corresponding FZ-i Series configuration, while the FX-500i is a good option for laboratories that already maintain suitable calibration weights.

Can the A&D FX-500i perform parts counting and checkweighing?

Yes. The FX-500i supports several useful weighing applications, including parts counting, percentage weighing, checkweighing/comparator functions, statistical calculations, and dynamic weighing. Its counting function also uses A&D's Automatic Counting Accuracy Improvement (ACAI) technology to improve piece-counting performance as additional samples are added.

Can the A&D FX-500i connect to a computer or laboratory data system?

Yes. The FX-500i includes RS-232C communication as standard. A&D also supports optional Quick USB, Ethernet, and Bluetooth connectivity solutions, allowing weighing data to be transferred to compatible computers, printers, and data-management equipment.
